Titan-II Series
Peak of Power & Intellect
The latest in cutting-edge LED linear high-bay technology, the lamparⒶRCH LLHB Titan-II Series is engineered to outshine standard fluorescent, metal halide high-bays, and even run-of-the-mill LED options. Boasting robust performance in a compact form, this luminaire is designed for superior industrial lighting.
Rep Portal Login
Login with your Sales Rep Account to see pricing & availabilityReset your password
We will send you an email to reset your password.
3-WATTselect:
85W|130W|155W Max
210W|255W|320W Max
330W|360W|400W Max
2-CCTselect:
4000K|5000K
The Apex High-Bay Solution
-
Warehouse & Storages
-
Production Facilities
-
Gymnasium Lighting
- Thermally isolated driver design with 0-10V dimming
- Die-cast aluminum for superior structural integrity
- Built-in 6KVa surge protection w/ option to add in-line surge protection
- The compact design not only reduces weight but also minimizes installation time, while delivering performance at the highest levels comparable to a full-sized linear high bay.
- Advanced lensing meets DLCv5.1 standard with optional distribution optics
- Eco-friendly packaging reduces packaging waste
- Standard suspend mounting hardware (included)
- 70% lumen maintenance at >100,000 hours
- The advanced driver is rated for AC97-305Vin
- Suitable for use in -40°F to 140°F
-
7Yrs, 75,000Hr
-
Replaces up to 2000W MH
-
50FT+ Placement
The lamparⒶRCH LLHB Titan-II series luminaire is the latest in high-performance LED linear highbay technology. Engineered to replace traditional fluorescent or metal halide highbays, the LLHB Titan-II delivers superior performance in a compact, easy-to-manage package.
-
Operating0°F0°F
Temp -
Ambient0°F0°F
Temp -
Efficacy>0lm/W
-
PF0
-
THD<0%
-
CRI>0
- Wattage selectable: 3-way dip-switch
- CCT selectable: 2-way dip-switch
- NLC Compliant, SIG-qualified Bluetooth Mesh lighting control
- Up to 400W, replacing up to 2,000W MH
Product Dimensions
Dimensions may vary, depending on the accessories.
Optional Accessories
Build to spec with bespoke accessories designed for the Titan-II
Note: All Titan-IIs come standard with V-hooks & 6ft aircraft cables for suspension
Build your Titan-II Series
Select the options below to build your own Titan-II Series model.
LLHB XXX -XXX XXX XXX XXX XXX XXX XXX
Rep Portal Login
Login with your Sales Rep Account to see request quoteReset your password
We will send you an email to reset your password.
Rep Portal Login
Login with your Sales Rep Account to see pricing & availabilityReset your password
We will send you an email to reset your password.
Overview
Fields marked with * are required. | Grayed out options are not selectable.
Model Series:
* 3-WATTselect (W)
* Voltage (V)
OPTIONAL: Emergency Driver
OPTIONAL: Motion Sensor
OPTIONAL: Step-Down Transformer
OPTIONAL: Wire Guard
OPTIONAL: Mounts
OPTIONAL: Optics
| Product | DLC ID | Models | Type | Controls | Watts | Lumens | Efficacy | CCT | White Tunable |
|---|---|---|---|---|---|---|---|---|---|
| LLHB085-2CS-UT/d/b | S-4CP19M | Premium | High-Bay Luminaires | Yes | 84.9 | 13062 | 153.77 | 4000 | TRUE |
| LLHB130-2CS-UT/d/b | S-AEH62D | Premium | High-Bay Luminaires | Yes | 128.5 | 19620 | 152.69 | 4000 | TRUE |
| LLHB155-2CS-UT/d/b | S-L5MOC7 | Premium | High-Bay Luminaires | Yes | 155.3 | 23469 | 151.14 | 4000 | TRUE |
| LLHB215-2CS-UT/d/b | S-SHCQIL | Premium | High-Bay Luminaires | Yes | 217.1 | 32881 | 151.07 | 4000 | TRUE |
| LLHB255-2CS-UT/d/b | S-IFKA6Y | Premium | High-Bay Luminaires | Yes | 252.5 | 38149 | 150.7 | 4000 | TRUE |
| LLHB320-2CS-UT/d/b | S-24XMG6 | Premium | High-Bay Luminaires | Yes | 322.6 | 49837 | 154.5 | 4000 | TRUE |
| LLHB400-2CS-UT/d/b | S-H03UNB | Premium | High-Bay Luminaires | Yes | 391.7 | 59742 | 152.54 | 4000 | TRUE |
