LRDW045-40-U3S

For competitive quote, log in to the portal and request a Special Project Quote

PRODUCT OVERVIEW

The cityⒶRCH roadway luminaire provides uncompromising optical performance and outstanding versatility for quick tool-less entry, superior lumen maintenance and surge protection options in a streamlined ultra low-profile design.

Engineered with low wind-resistance, surface electrostatic treatment for coastal applications, the LRDW-series is ideal for walkways, roadways and general lighting.

LRDW-features

KEY FEATURES

  • Heavy duty die-cast aluminum housing
  • Single latch tool-less entry door to driver components
  • 3G vibration rated, constructed for harsh environmental applications
  • Housing is sealed and protected against moisture and contaminants
  • 100,000hr led lifespan based on IES lM-80 and TM-21 calculations
  • Standard finish: silver, optional finish in black, bronze and white
  • Dark sky conforming optics available in IES Type III, IV, or V
  • Scalable lumen packages, replacing up to 400W MH
  • Optional photocell and occupancy sensors available

ORDERING GUIDE

Model Series

Watt (W)

CCT (K)

Voltage (V)

Photometry

Finish

Photocell (a)

PIR Sensor























LRDW | LED Roadway

45 45W
70 70W
100 100W
150 150W

30 3000K
35 3500K
40 4000K
50 5000K

U | 120-277V
H | 347-480V

2 | Type-II
3 | Type-III *
4 | Type-IV

B |
D |
W |
S |

Black
Dark Bronze
White
Silver *

Blank |
PU |
PH |

None *
120-277V
480V

Blank |
MS |

None *
PIR Motion Sensor

* Default option

Choose Your Model Specifications Above:



LRDW

100

50

U

3

S

PU

MS

Example Ordering Number: LRDW100-50-U3S-PU-MS



KEY SPECIFICATIONS

  • Housing: Thermally conductive heavy-duty die cast aluminum
  • Input Voltage: 120-277Vac or 347-480Vac
  • Operating Temp: -40°F — 150°F
  • Efficacy: 130LM/W to 140LM/W
  • IP: UL Wet Location Listed
  • PF: >0.9 Non-Flicker
  • Dimming: 1-10V
  • THD: <20%
  • CRI: >70

APPLICATIONS
TITAN_APP

CERTIFICATIONS
Certifications

STANDARD WARRANTY*
7YRS

* Extended warranty available

MODEL SPECIFICATIONS

Model

Watt

Lumens

Voltage

CCT

LPW

Replaces

LRDW045

45W

6,350LM

120-277V

347-480V





3000K

3500K

4000K

5000K

140LM/W

100W MH

LRDW070

70W

9,400LM

135LM/W

250W MH

LRDW100

100W

14,700LM

138LM/W

320W MH

LRDW150

150W

20,000LM

135LM/W

400W MH

SIZING & MEASUREMENTS

Model

Length (in)

Width (in)

Depth (in)

Weight (lb)

LRDW-dim

LRDW045

23.84

4.52



6.50 w/ photocell

10.43

8.35

LRDW070

8.66

LRDW100

9.46

LRDW150

10.10
