LLHB2110-xx-U2

For competitive quote, log in to the portal and request a Special Project Quote
Size ◦ Wattage ◦ Voltage
CCTselect

PRODUCT OVERVIEW

* Options shown are pre-built in-stock items.  We may install all available accessories prior to ship as part of our workbench assembly service.

Loading store locator from Stockist store locator...

Documentation Downloads

feat

ORDERING GUIDE

Model Series

Length (FT)

Watt (W)

CCT (K) [xx]

Voltage (V)

Motion Sensor

EM Driver

LLHB | LED Linear Highbay

2 | 2FT

110 110W
130 130W
160 160W
170 170W

-xx CCTselect:

  • 3000K
  • 4000K
  • 5000K

-U2 | 120-277V

Blank |
-ASN |

None *
Bi-Level Sensor

Blank |
-EM15 |

None *
15W EM Battery

4 | 4FT

255 255W
300 300W
400 400W

*  Standard option
** Integral Controls & Emergency Drivers

Choose Your Model Specifications Above:

LLHB

4

300

-xx

-U2

-ASN

-EM15

Example Ordering Number:
LLHB4300-xx-U2-ASN-EM15

MODEL SPECIFICATIONS

Model

Watt

Lumens

Voltage

CCT

Replaces

LLHB2110

110W

13,750LM

120-277V

3000K
4000K

5000K

300W MH

LLHB2130

130W

16,250LM

500W MH

LLHB2160

160W

20,000LM

800W MH

LLHB2170

170W

21,250LM

1000W MH

LLHB4255

255W

31,875LM

1300W MH

LLHB4300

300W

37,500LM

1500W MH

LLHB4400

400W

55,000LM

2000W MH

SIZING & MEASUREMENTS

Dimension (FT)

Width (in)

Length (in)

Depth (in)

Weight (lb)

2FT

15.00

25.00

1.87

16.60

4FT

15.00

46.50

2.17

31.20

⚠️  PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION

  • Please read the product specification carefully first to confirm that the working environment is in line with the condition on the specification before it is used.
  • Please confirm the input voltage and frequency before use.
  • The light must be installed by professional personnel
  • If the power cord and case of the products are damaged, it will be regarded as disqualified product and should not be used.
  • If external soft cable or wire of the product is damaged, the wire should be replaced by manufacturer or service agent or personnel with similar qualification to avoid danger.
  • This luminaire is designed to operate in ambient temperatures ranging from -22°F to 158°F and to be horizontally mounted facing down.
  • This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved.
  • This product is not available for several special environments, such as places with corrosive gas liquids or high pressure water vapor.
  • CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT CONDUCTOR
  • CAUTION - RISK OF FIRE

INSTALLATION INSTRUCTIONS

Suspended Mount

1

2

3

  1. Assemble the chain w/ V-hook.
  1. Insert the v-hook into the slots as shown.
  1. Connect the chain onto the ceiling anchors.

4

5

6

  1. Turn OFF power & make the wiring connections with thermal cap.
  1. Insert the terminal cap and wires into the driver box.
  1. Insert the wire terminal joint to the air entry.

Pendant Mount

1

2

3

  1. Assemble the chain w/ V-hook.
  1. Insert the v-hook into the slots as shown.

4

5

6

  1. Connect the chain onto the ceiling anchors.
  1. Turn OFF power & make the wiring connections with thermal cap.
  1. Insert the terminal cap and wires into the driver box.

Sensor Install

1

2

  1. Unscrew the nut on the base of the motion sensor.
  1. Install the sensor lens and tighten the screws.
